Rotary head boosts component mountability of tiny components. This maintains high speed production since head replacements are no longer needed. This is technology that helps carry on the 1 head solution concept. This head can handle components ranging from super-tiny 0201mm components on up to medium-sized odd-shaped components of 12 x 12mm dimensions with heights of 6.5mm
Utilizes the overdrive motion from Σ technology that minimizes the interference range between 2 heads to achieve higher production efficiency.
The new high-speed feeder is lined up for the RM head that achieves high productivity. Component feed speed is drastically improved for the super high-speed RM head component pickup.
The dual-stage conveyor has evolved to an even higher level, with enhanced PCB handling capability (maximum PCB width 510mm). High-speed PCB conveying drastically cuts the time needed for PCB changeovers.
The all-around type head that can provide not only high-speed but also high flexibility handling from super-tiny 0201mm components on up to large-size components of 55 x 100mm and heights to 15mm. Combining the HM head with the RM head realizes high-speed mounting of all types of components.
Ultra wide-range head capable of handling components ranging from super-tiny 03015mm chips to tall components to 30mm and ultra-large components of 55 x 100mm. Force control is also available.
Achieving a common platform allows selecting from 1-beam and 2-beam for configuring the X-axis according to production mode and mounting capability.
Light weight nozzles are essential standard equipment for ensuring high-speed, low-impact mounting, which is essential for mounting super-tiny components next to each other in narrow spaces. These come with nozzle IDs and improved maintenance features.
The component recognition camera can flexibly switch between line imaging and area imaging. The side-view camera improves quality for mounting of tiny components.Coplanarity checker can also be installed as an option.
Self-diagnosis and self-recovery functions continuously maintain nozzles and feeders in a clean state for continuous high-quality production.
Provides a nonstop supply of tray components in pallet or magazine unit. – Achieves streamlined refilling of tray components and non-stop production.
The preset function of the Auto loading feeder reduces the load on the operator by widening out the component supply timing.
This automatically positions the pushup pins. Using along with the automatic program change over function drastically reduces the workload during production changeovers.
